ABB PFEA112-20 Tension measurement and control module

ABB PFEA112-20 Tension measurement and control module

summarize
The PFEA112-20 is part of ABB’s family of electric drives, which are used to accurately measure and control tension in various industrial processes, ensuring the stability of production processes and the consistency of product quality.

Functional characteristics
High-precision measurement: Using advanced sensor technology and signal processing algorithm, it can accurately measure the tension value, the measurement accuracy can reach ±0.1% FS (full scale), providing an accurate data basis for tension control.
A variety of measurement ranges: support a variety of tension measurement ranges, according to the actual application needs to choose different ranges, such as 0-100N, 0-500N, 0-1000N, to meet the tension measurement requirements in different industrial scenarios.
Analog output: Two analog output channels can provide analog signals proportional to the measured tension value, usually 0-10V or 4-20mA signals, for easy connection and integration with other control systems or devices.
Digital communication interface: Equipped with RS-485 communication interface, support Modbus RTU communication protocol, can achieve high-speed data transmission and communication with the host computer or other intelligent devices, easy to remote monitoring and parameter setting.
Flexible parameter setting: Through the dedicated configuration software or field operation panel, you can easily set and adjust various parameters of the module, such as measurement range, filtering time constant, output gain, etc., to adapt to different application scenarios and control requirements.
Fault diagnosis and protection function: with a perfect fault diagnosis and protection mechanism, it can monitor its own working status in real time, when there is an abnormal situation, such as sensor failure, communication failure, overload, etc., it will send an alarm signal in time, and take corresponding protective measures to ensure the safety of equipment and production process.

Technical parameter
Power supply voltage: 24V DC (±10%), with good power supply adaptability, can work stably in a certain range of voltage fluctuations.
Power consumption: Typical power consumption is less than 5W, and the low-power design helps to reduce energy consumption and heat dissipation requirements.
Operating temperature range: -20℃ to + 70℃, storage temperature range of -40 ℃ to + 85℃, suitable for a variety of industrial environment temperature conditions.
Protection level: IP20, suitable for indoor relatively clean environment, usually installed in the control cabinet or electrical equipment inside.
Application field
Textile industry, paper industry, printing industry, cable manufacturing industry.
