HONEYWELL LG1093AA24 261A1812P012 UV flame sensor

HONEYWELL LG1093AA24 261A1812P012 UV flame sensor

HONEYWELL LG1093AA24 261A1812P012 is an ultraviolet flame sensor manufactured by Honeywell.

peculiarity
High sensitivity: extremely weak flame can be detected, and even a very small flame signal can be accurately captured to ensure the timely discovery of the flame.
Fast response: The response time is less than 10 milliseconds, and the appearance of the flame can be sensed in a very short time, which helps to quickly take appropriate safety measures or control operations.
Strong anti-interference ability: can effectively filter out interference signals from sunlight, welding light and other light sources, to ensure that the flame can be accurately detected under complex ambient light conditions to avoid false positives.
Rugged: With a rugged design, it can withstand harsh environmental conditions, can adapt to the operating temperature range of -40 °C to 85°C, and the protection level reaches IP65. It can work stably in the environment with dust and water splash.
Compliance standards: Meet UL, FM, CSA and other relevant certification standards, product quality and performance are reliably guaranteed.

Technical parameter
Detection range: The wavelength range is 250 to 350 nanometers, which is the region of the ultraviolet spectrum associated with the characteristic radiation of the flame, allowing the sensor to specifically detect the ultraviolet light emitted by the flame.
Sensitivity: Less than 5mW/cm², the high sensitivity allows it to respond to weak flame UV radiation.
Field of view Angle: 80° field of view Angle, can cover a large observation range, can effectively detect the flame in a certain Angle range.

Installation points
Field of view requirements: It should be installed in a position where the flame can be clearly observed to ensure that the flame is within its field of view to ensure that the sensor can effectively receive the ultraviolet signal of the flame.
Avoid interference: Keep away from light sources and equipment that may cause interference, such as direct sunlight, welding operation areas, etc., to prevent interference signals from affecting the normal work of the sensor, resulting in misjudgment.
Fixed installation: It must be installed on a solid surface and ensure that it is firmly installed to avoid vibration, collision and other factors affecting the performance and stability of the sensor.
